基于CF模型的斜坡地质灾害孕灾因子敏感性分析——以湖南省新宁县为例

刘中楠; 高银梅; 姜河; 黄勇炜; 丁华栋; 颜智强

doi:10.19388/j.zgdzdc.2023.04.13

基于CF模型的斜坡地质灾害孕灾因子敏感性分析——以湖南省新宁县为例

1.
湖南省地球物理地球化学调查所,湖南长沙 410000
2.
河南地矿职业学院,河南郑州 450000
3.
南华大学,湖南衡阳 421000

基金项目: 中央财政项目“湖南省宁县1∶10 000地质灾害调查和风险评价(编号: 2022430032)”资助

详细信息

作者简介:
刘中楠(1992—),男,工程师,主要从事地质灾害调查及研究工作。Email: 443149421@qq.com。

中图分类号: P694
计量
- 文章访问数: 60
- HTML全文浏览量: 0
- PDF下载量: 47
出版历程
- 收稿日期: 2022-11-30
- 修回日期: 2023-07-13
- 刊出日期: 2023-08-19

Sensitivity analysis of inducing factors of slope geological hazards based on CF Model: A case study of Xinning County in Hunan Province

1.
Hunan Geophysical and Geochemical Survey Institute, Hunan Changsha 410000, China
2.
Henan Geology and Mining Vocational College, Henan Zhengzhou 450000,China
3.
University of South China, Hunan Hengyang 421000, China

摘要

摘要: 在不同的区域及地质背景下,斜坡地质灾害的主控因子及其影响程度各不相同,分析孕灾因子的敏感性,有利于提高斜坡地质灾害预测的准确性。在资料收集和实地调查工作的基础上,选取了坡度、高程、剖面曲率、地层、斜坡结构、断裂、河流和归一化植被指数(normalized difference vegetation index,NDVI)共8个因子作为斜坡地质灾害的孕灾因子; 基于GIS平台,采用确定性系数(certainty factor, CF)模型进行敏感性分析,并通过敏感性指数评价各因子的敏感性大小并划分敏感性分区。结果表明: 坡度≥40°、高程[600,700 m)、剖面曲率≥0.6、三叠系和二叠系、顺向坡、距断层距离[0,500) m、距河流距离[0,200) m以及NDVI为[0.233, 0.595)最容易发生灾害,由高到底划分为极高、高、中、低和极低5个敏感区,同时采用2020—2021年的灾害数据进行了验证,87.50%的灾害位于高敏感区和极高敏感区内,证实了敏感性分析的合理性。研究成果为下一步风险评价工作奠定了基础,为防灾减灾工作提供了参考,也可为湖南省其他县区提供借鉴。
- 斜坡地质灾害 /
- 孕灾因子 /
- CF模型 /
- 敏感性分析 /
- 新宁县
Abstract: The main controlling factors of slope geological hazards and their influence degrees are different in different regions and geological backgrounds. Analyzing the sensitivity of hazard inducing factors is beneficial to improve the accuracy of slope geological hazards prediction. On the basis of data collection and field investigation, the authors in this research selected eight factors, including slope, elevation, profile curvature, stratum, geolo-gical time, slope structure, fault, river and normalized difference vegetation index (NDVI), as the inducing factors of slope geological hazards. The sensitivity analysis is conducted by the certainty factor (CF) model based on GIS platform, and the sensitivity index was used to analyze the sensitivity of each factor and divide the sensitivity zones. The results show that areas with the most prone to disasters included characteristics of slope ≥40°, elevation [600,700) m, profile curvature ≥0.6, Triassic and Permian, along slope, [0, 500) m from the fault, [0, 200) m from the river and NDVI between [0.233, 0.595). The sensitivity was divided into five sensitive zones, namely extremely high, high, medium, low and extremely low. At the same time, the disaster data from 2020 to 2021 were used to verify that 87.50% of the disasters were located in extremely high and high sensitive areas, verifying the rationality of this study. The research results lay a foundation for the next step of risk assessment, and provide a reference for disaster prevention and for other counties and districts in Hunan Province.
- slope geological disaster /
- hazards inducing factors /
- CF model /
- sensitivity analysis /
- Xinning County

HTML全文

参考文献(23)

[1]	文武飞,李雪宇,赵帅军,等.湖南省山丘区居民切坡建房形成地质灾害隐患与防治对策[J].国土资源导刊,2020,17(3):37-41. Wen W F,Li X Y,Zhao S J,et al.The formation of geological ha-zard hidden danger and its prevention and cure countermeasure of residential houses built in hilly regions of Hunan Province[J].Land & Resources Herald,2020,17(3):37-41.
[2]	谈树成,金艳珠,虎雄岗,等.斜坡地质灾害气象预报预警空间数据库的设计与建立[J].地球学报,2012,33(5):812-818. Tan S C,Jin Y Z,Hu X G,et al.The design and establishment of meteorological forecasting and warning spatial database of slope geological hazards[J].Acta Geoscientica Sinica,2012,33(5):812-818.
[3]	刘康,田臣龙,徐凤琳.基于信息量-层次分析耦合模型的泗水县地质灾害易发性评价[J].中国地质调查,2023,10(2):77-86. Liu K,Tian C L,Xu F L.Susceptibility assessment of geological disasters in Sishui County based on the coupling model of Information Content and Analytic Hierarchy Process method[J].Geological Survey of China,2023,10(2):77-86.
[4]	王存智,张炜,李晨冬,等.基于GIS和层次分析法的沙溪流域滑坡地质灾害易发性评价[J].中国地质调查,2022,9(5):51-60. Wang C Z,Zhang W,Li C D,et al.Susceptibility evaluation of landslide hazards of Shaxi river basin based on GIS and AHP[J].Geological Survey of China,2022,9(5):51-60.
[5]	覃乙根,杨根兰,谢金,等.贵州省开阳县斜坡地质灾害孕灾因子敏感性分析[J].煤田地质与勘探,2020,48(4):190-198. Qin Y G,Yang G L,Xie J,et al.Sensitivity analysis of disaster-pregnant environmental factors for slope geological hazards in Kaiyang County,Guizhou Province[J].Coal Geology & Exploration,2020,48(4):190-198.
[6]	牛全福,冯尊斌,党星海,等.黄土区滑坡研究中地形因子的选取与适宜性分析[J].地球信息科学学报,2017,19(12):1584-1592. Niu Q F,Feng Z B,Dang X H,et al.Suitability analysis of topographic factors in loess landslide research[J].Journal of Geo-Information Science,2017,19(12):1584-1592.
[7]	刘月,王宁涛,周超,等.基于ROC曲线与确定性系数法集成模型的三峡库区奉节县滑坡易发性评价[J].安全与环境工程,2020,27(4):61-70. Liu Y,Wang N T,Zhou C,et al.Evaluation of landslide susceptibility based on ROC and certainty factor method in Fengjie County,Three Gorges Reservoir[J].Safety and Environmental Engineering,2020,27(4):61-70.
[8]	杨静,丁俊,王辉.基于GIS和加权信息量的临湘市地质灾害易发性评价[J].测绘地理信息,2020,45(3):51-53,57. Yang J,Ding J,Wang H.Evaluation of geological disaster susceptibility in Linxiang city based on GIS and weighted information value[J].Journal of Geomatics,2020,45(3):51-53,57.
[9]	肖谆,肖其鹏,万方良,等.湖南省临武县黄寿湾村岩溶塌陷易发程度分区研究[J].矿产与地质,2020,34(1):159-165. Xiao Z,Xiao Q P,Wan F L,et al.Study on occurrence possiblity zonation of karst collapse in Huangshouwan Village of Linwu County,Hunan[J].Mineral Resources and Geology,2020,34(1):159-165.
[10]	赵祈溶,曹顺红,文武飞,等.基于证据权法的湖南省石门县皂市水库滑坡易发性评价[J].华南地质,2021,37(2):216-225. Zhao Q R,Cao S H,Wen W F,et al.Landslide susceptibility eva-luation based on weights of evidence method for the Zaoshi reservoir in Shimen county,Hunan Province[J].South China Geology,2021,37(2):216-225.
[11]	雷帆,刘博.基于ArcGIS信息量模型的宁远县地质灾害易发性评价与区划[J].国土资源导刊,2015,12(2):80-84,65. Lei F,Liu B.Susceptibility assessment and zoning of geo-hazards in Ningyuan County based on the ArcGIS information model[J].Land & Resources Herald,2015,12(2):80-84,65.
[12]	刘江龙,柳建新,吴湘滨,等.湖南怀化市坡面地质灾害发育特征与人为致灾因子分析[J].灾害学,2011,26(2):39-44. Liu J L,Liu J X,Wu X B,et al.Analysis on development characteristics of slope geological calamity and artificial disaster-causing factors in Huaihua City,Hunan Province[J].Journal of Catastrophology,2011,26(2):39-44.
[13]	Shortliffe E H,Buchanan B G.A model of inexact reasoning in medicine[J].Mathematical Biosciences,1975,23(3-4):351-379.
[14]	Heckerman D.Probabilistic interpretations for MYCIN’s certainty factors[C]//Proceedings of the First Conference on Uncertainty in Artificial Intelligence.Los Angeles:AUAI Press,1985:9-20.
[15]	李益敏,谢亚亚,蒋德明,等.怒江州斜坡地质灾害孕灾环境因素敏感性研究[J].水土保持研究,2018,25(5):300-305. Li Y M,Xie Y Y,Jiang D M,et al.Study on sensitivity in disaster-pregnant environmental factors of slope geological hazards in Nujiang prefecture[J].Research of Soil and Water Conservation,2018,25(5):300-305.
[16]	冯杭建,周爱国,唐小明,等.基于确定性系数的降雨型滑坡影响因子敏感性分析[J].工程地质学报,2017,25(2):436-446. Feng H J,Zhou A G,Tang X M,et al.Susceptibility analysis of factors controlling rainfalltriggered landslides using certainty factor method[J].Journal of Engineering Geology,2017,25(2):436-446.
[17]	温鑫,范宣梅,陈兰,等.基于信息量模型的地质灾害易发性评价:以川东南古蔺县为例[J].地质科技通报,2022,41(2):290-299. Wen X,Fan X M,Chen L,et al.Susceptibility assessment of geological disasters based on an information value model:A case of Gulin County in Southeast Sichuan[J].Bulletin of Geological Science and Technology,2022,41(2):290-299.
[18]	张钟远,邓明国,徐世光,等.镇康县滑坡易发性评价模型对比研究[J].岩石力学与工程学报,2022,41(1):157-171. Zhang Z Y,Deng M G,Xu S G,et al.Comparison of landslide susceptibility assessment models in Zhenkang County,Yunnan Pro-vince,China[J].Chinese Journal of Rock Mechanics and Engineering,2022,41(1):157-171.
[19]	田春山,刘希林,汪佳.基于CF和Logistic回归模型的广东省地质灾害易发性评价[J].水文地质工程地质,2016,43(6):154-161,170. Tian C S,Liu X L,Wang J.Geohazard susceptibility assessment based on CF model and Logistic Regression models in Guangdong[J].Hydrogeology & Engineering Geology,2016,43(6):154-161,170.
[20]	薛强,张茂省,李林.基于斜坡单元与信息量法结合的宝塔区黄土滑坡易发性评价[J].地质通报,2015,34(11):2108-2115. Xue Q,Zhang M S,Li L.Loess landslide susceptibility evaluation based on slope unit and information value method in Baota District,Yan'an[J].Geological Bulletin of China,2015,34(11):2108-2115.
[21]	王文坡,韩爱果,任光明,等.四川省普格县滑坡孕灾环境因子敏感性分析[J].长江科学院院报,2018,35(9):63-67,97. Wang W P,Han A G,Ren G M,et al.Sensitivity analysis of hazard-brewing environmental factors of landslides in Puge County of Sichuan Province[J].Journal of Yangtze River Scientific Research Institute,2018,35(9):63-67,97.
[22]	胡燕,李德营,孟颂颂,等.基于证据权法的巴东县城滑坡灾害易发性评价[J].地质科技通报,2020,39(3):187-194. Hu Y,Li D Y,Meng S S,et al.Landslide susceptibility evaluation in Badong County based on weights of evidence method[J].Bulletin of Geological Science and Technology,2020,39(3):187-194.
[23]	屠水云,张钟远,付弘流,等.基于CF与CF-LR模型的地质灾害易发性评价[J].中国地质灾害与防治学报,2022,33(2):96-104. Tu S Y,Zhang Z Y,Fu H L,et al.Geological hazard susceptibility evaluation based on CF and CF-LR model[J].The Chinese Journal of Geological Hazard and Control,2022,33(2):96-104.
